UMI 93-02 Camaro Firebird Hardtop Tubular Subframe Connectors - Weld-In Black

1964-1972 GM A-Body 1" Tubular Rear Sway Bar, Chassis Mounted
Red Powdercoat
3" Axle Tube Diameter

Made in the USA!

Please Measure Your Axle Tube Diameter PRIOR to ordering
"Factory rear end, Strange Engineering and Currie rear ends use 3" diameter axle tubes
"Moser Engineering 12-bolt rear ends use 3" diameter axle tubes
"Moser Engineering 9" rear ends manufactured after early 2002 use 3" axle tubes. Rear ends manufactured prior to early 2002 use 3.25" axle tubes. Please verify diameter before ordering.
"Other brand rear ends will vary, please check your axle tube diameter before ordering.

This item is for the 3" Diameter Axle Tubes.

• Applications:
• 1964 - 1972 Chevrolet Chevelle, Monte Carlo, Malibu, El Camino
• 1964 - 1972 Buick Skylark, Grand Sport, Special
• 1964 - 1972 Pontiac Lemans, GTO
• 1964 - 1972 Oldsmobile Cutlass, 442, F-85

UMI's A-body Pro-Touring style bar is a true multi purpose high performance rear sway bar. The chassis and differential housing mounts reduce bind normally associated with the factory style bars. The bars are 1" diameter hollow and feature three different rates (street/auto-x, road race/strip). UMI's tried and true CNC machined clamping systemallows differential housing mounting on 3" and 3.25" diameter housings (This item is for the 3" Housing, please see our other items if you have a 3.25" Housing). These can be bolted on, or welded for additional security. The double shear chassis mounts are held in place by four 3/8" fasteners. Drilling through the crossmember is required and a template /instructions are included. The house made hex adjusterallows pre-loading of the bar when used for drag applications so your car leaves straight. Choose the longest hole for street, middle hole for auto-x, road race and the shortest hole for drag use!

Features:
"Light weight 1" tubular sway bar, CNC bent

"Designed to clear all rear ends- 10-Bolt, 12-Bolt, 9", M9, S60 and others

"Heavy duty race style chromoly spherical rod ends with Teflon race

"High strength 4140 chromoly zinc-plated u-bolts

"CNC machined sway bar mounts with grip teeth and reinforcement gussets

"1" Billet steel hex adjuster for extreme strength

"Premium greaseable polyurethane bushings

"100% bolt in installation!

"Durable long lasting powder coat

Warranty: UMI Performance offers a 2 Year replacement Warranty from the original purchase date to the original purchaser of the parts.

Also available in Black Powdercoat:
Click Here to see our other options

UMI Performance proudly designs and manufactures its entire line of products within its facility located in the small town of Philipsburg, Pennsylvania. The facility features CNC machining, both milling and turning CNC's, band sawing, press brake operation, MIG and TIG welding, sand blasting, plasma cutting and powder coating.
