201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable

201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable

Each
$189.99
Skip to product information
201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
  • 201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable
201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable

201520 – 1982-2002 GM F-Body Rear Control Arm Panhard Bar Kit, Non-Adjustable

$189.99

This UMI kit replaces factory lower control arms and panhard bar with tubular DOM steel versions. Bolt-on installation, polyurethane bushings, and grease fittings improve handling, reduce wheel hop, and enhance rear stability.

Details

This kit replaces your factory lower control arms and panhard bar with heavy duty tubular versions. These bolt-on replacements minimize wheel hop, improve cornering, and help with track consistency. The panhard bar increases rear stability and controls side movement, while the control arms reduce wheel hop. Both are made of Seamless DOM mild steel tubing for added strength over aluminum versions. They are CNC machined and TIG welded with polyurethane bushings, zinc plated steel sleeves, and grease fittings for easy maintenance. Installation is quick and easy, taking approximately 30 minutes using OEM hardware in factory mounting points.

Description

201520 - 1982-2002 GM F-Body Tubular Lower Control Arms, Non-Adj Panhard Bar Kit

Short Description

F-Body Kit

Application Summary

UMI designed 201520 to fit 1982-2002 GM F-Body vehicles

Features

  • Control Arms Built Using 1.625" x 0.120" Steel DOM Tubing
  • Panhard Bar Built Using 1.250" x 0.095" Steel DOM Tubing
  • TIG Welded Construction
  • CNC Machined Zinc Plated Steel Sleeves
  • High Quality Fluted Polyurethane grease-able Bushings
  • Durable Powder Coat Finish
  • Uses OEM Hardware

Product Info

Part Number 201520-R
Part Type Suspension Trailing Arm / Panhard Rod Kit
Warranty Time 2
Warranty UOM YR
Condition NEW
Lifecycle Status Available to Order
HS Code 8708807000
Country of Origin US

Available Packages

Package Qty Weight Dimensions GTIN
Each 1 18.0 lb L 47.0 x W 6.0 x H 6.0 Inches

Specifications

Adjustable No
Bushing Color Red
Bushing Material Polyurethane
Bushings Included Yes
California Proposition 65 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Color Red
Construction Tubular
End 1 Type Polyurethane
End 2 Type Polyurethane
Finish Black Powdercoated, Red Powdercoated
Front Or Rear Suspension Rear
Grade Type Performance
Grease Fitting Included Yes
Material Steel
Mounting Hardware Included No

Fitment

Year Make Model Submodel
1982-2002 Chevrolet Camaro
1982-2002 Pontiac Firebird
