1968 - 1972 GM A-Body Tubular Upper & Lower Control Arms
Black Powdercoat

Made in the USA!

• Applications:
• 1968 - 1972 Chevrolet Chevelle, Monte Carlo, Malibu, El Camino
• 1968 - 1972 Buick Skylark, Grand Sport, Special
• 1968 - 1972 Pontiac Lemans, GTO
• 1968 - 1972 Oldsmobile Cutlass, 442, F-85

This is a complete rear suspension kit and includes all items needed to rebuild the rear suspension on your 64-72 A-Body. This kit includes tubular lower control arms, tubular upper controls, adjustable frame braces, rear end housing bushings, 1" solid sway bar and new Grade 8 hardware. This is a direct bolt in kit and requires no welding or modifications. Control arms feature grease-able Energy Suspension bushings and are constructed of DOM steel tubing. The lower control arms feature reinforced sway bar holes to work with the new solid chrome moly sway bar. The included frame braces are a direct bolt on and do not require denting the floor boards like our competitors design, they are bent to follow the contour of the vehicles floor board. This entire kit is manufacture by UMI Performance and made in the USA

Upper Arms

Rear control arms are one of the most important suspension modifications that can be done to your GM vehicle. Stock control arms are on the borderline of junk, bushing deflection and rusting weak stamped material add for traction loss and poor handling ability. Our tubular control arms are designed to give you the best of both worlds, whether your car is a weekend cruiser or a weekend track addict we got you covered. The included Energy Suspension polyurethane bushings are an excellent improvement over OEM rubber bushings, while adding ride improvements they also work excellent to reduce traction loss. These control arms are a direct bolt-on replacement designed to minimize wheel hop, improve corning and help track consistency.

• Features:
• Built using 1.625" OD x 0.120" DOM Mild Steel Tubing
• CNC machined for Precision Tolerances and Accuracy
• Fully TIG and MIG Welded Construction
• Energy Suspension Polyurethane Bushings with Grease Fittings
• Durable Long Lasting Powder Coat finish

Lower Arms:

Rear lower control arms are a must improvement for any General Motors A-Body vehicle. Our lower control arms our designed to replace your weak, rusted, factory-stamped arms, adding strength, rigidity and bushing improvement. Built using strong DOM steel tubing these direct bolt on replacements help eliminate unwanted wheel hop while improving corning and helping much needed track consistency. Lower Control arms feature CNC Machined 0.120" wall thickness mild steel tubing, fully TIG welded construction, greaseable polyurethane bushings and zerk grease fittings all combined to make the best arms on the market!

• Features:
• 0.500" OD x 0.120" DOM mild steel tubing
• CNC machined for precision tolerances and accuracy
• Fully TIG welded for superior strength
• Greaseable Energy Suspension fluted bushings
• Reinforced sway bar holes
• Durable long lasting powder coat finish
• Features Reinforced Sway Bar Holes - Works with OEM Sway Bar and Most Aftermarket Sway Bars

1968-1972 GM A-Body Control Arm Reinforcements/Frame Braces

Trailing arm mount braces are designed to reinforce the upper and lower front control arm mounts on your classic A-Body. The more power your ride makes the better chance of bending or breaking the rear control arm mounts. These tubular reinforcements tie the upper and lower control arm mounts together for added strength and driving performance. The UMI Performance braces are bent to contour the floor of the vehicle, unlike our competitor's designs these reinforcements do not require the floor to be dented or pounded for correct fitment. Control arm braces are manufactured from DOM steel; TIG welded and feature adjustment for a perfect fit on all 68-72 A-Body's. Kit includes new longer Grade 8 hardware, nuts and washers.

1964 - 1972 GM A-Body 1" Solid Chromoly Rear Sway Bar

Trailing arm mount braces are designed to reinforce the upper and lower front control arm mounts on your classic A-Body. The more power your ride makes the better chance of bending or breaking the rear control arm mounts. These tubular reinforcements tie the upper and lower control arm mounts together for added strength and driving performance. The UMI Performance braces are bent to contour the floor of the vehicle, unlike our competitor's designs these reinforcements do not require the floor to be dented or pounded for correct fitment. Control arm braces are manufactured from DOM steel; TIG welded and feature adjustment for a perfect fit on all 68-72 A-Body's. Kit includes new longer Grade 8 hardware, nuts and washers.

Warranty: UMI Performance offers a 2 Year replacement Warranty from the original purchase date to the original purchaser of the parts.

Also available in Red Powdercoat:
Click Here to see our other options

UMI Performance proudly designs and manufactures its entire line of products within its facility located in the small town of Philipsburg, Pennsylvania. The facility features CNC machining, both milling and turning CNC's, band sawing, press brake operation, MIG and TIG welding, sand blasting, plasma cutting and powder coating.
