UMI Performance 1046-R Ford Mustang Rear Tubular Upper Control Arm - Red

1982 - 2002 GM F-Body Single Adjustable Lower Control Arms and Panhard Bar Kit
Red Powdercoat

Made in the USA!

• pplication:
• 1982 - 2002 Chevrolet Camaro
• 1982 - 2002 Pontiac Firebird

Replace your weak, factory stamped lower control arms with UMI's heavy duty tubular adjustable set up. These direct bolt-on replacements minimize wheel hop, improve cornering while lowering ET's and helping track consistency. The spherical rod endallows for a "Bind Free" operation making a great upgrade for both your track and auto cross driven car. The polyurethane bushings are designed to be bolted to the car chassis for a quiet comfortable operation. Control arms are constructed DOM mild steel tubing 1.375" OD x 0.095" wall, 4130 chrome moly threaded tube adaptors, completely CNC machined and fully TIG welded for outstanding strength. Control arms feature Energy Suspension polyurethane bushings, zinc plated steel sleeves and on-car grease-able grease fittings. Adjustments can be made using the high quality QA1 Teflon lined spherical rod end that operates for a quiet bind free performance

• Features:
• .375" x 0.095" DOM Mild Steel Tubing


• 130 Chrome-Moly Threaded Tube Adaptor


• QA1 3/4" Hard Chrome Plated, Teflon/Kevlar Self Lubricating Race Rod End


• Complete Arm Features TIG Welded Construction


• CNC Machined 6061 Aluminum Step Bushings with Zinc Plated Steel Sleeves


• Energy Suspension Fluted Polyurethane grease able Bushings


• Uses OEM Hardware

Installation: Installs in approximately 30 minutes in factory mounting points using OEM hardware, the poly end is designed to be bolted to the chassis for a quiet, comfortable operation.

Tubular Single Adjustable Panhard Bar

This tubular single adjustable panhard bar replaces the flimsy stock stamped panhard bar while adding increased strength and rear end adjustment. This is a must for rear end centering after vehicle lowering, as well as clearance for running larger tires. The supplied rod endallows for adjustments off the car to quickly lengthen or shorten the panhard bar once a desired length is accomplished. The spherical rod end/polyurethane bushing combination eliminates most rear end "bind" while not sacrificing your ride quality; this is an excellent improvement for your street or drag application.

• Features:
• 1.250" x .095" DOM Steel Tubing
• 130 Chrome-Moly Threaded Tube Adaptor
• QA1 3/4" Hard Chrome Plated, Teflon/Kevlar Self Lubricating Race Rod End
• Precision TIG Welded Construction
• CNC Machined 6061 Aluminum Step Bushings for a Centered Fit with the Mounting Point
• Energy Suspension Grease able Polyurethane Bushings with Grease Fittings
• Uses OEM Hardware, installs in 20 minutes
• Brilliant Durable Powder Coat Finish

Tubular Adjustable Lower Control Arms

Replace your weak, factory stamped lower control arms with UMI's heavy duty tubular adjustable setup. These direct bolt-on replacements minimize wheel hop, improve cornering while lowering ET's and help track consistency. The spherical rod endallows for a "bind free" operation, making a great upgrade for both your track and auto cross driven car. The polyurethane bushings are designed to be bolted to the car chassis for a quiet comfortable operation. Control arms are constructed DOM mild steel tubing 1.375" OD x 0.095" wall, 4130 chrome moly threaded tube adaptor, completely CNC machined and fully TIG welded for outstanding strength. Control arms feature Energy Suspension polyurethane bushings, zinc plated steel sleeves and "on-car" grease able zerk grease fittings. Adjustments can be made using the high quality QA1 Teflon lined spherical rod end that operates for a quiet bind free performance.

• Features:
• .375" x 0.095" DOM Mild Steel Tubing
• 130 Chrome-Moly Threaded Tube Adaptor
• QA1 3/4" Hard Chrome Plated, Teflon/Kevlar Self Lubricating Race Rod End
• Complete Arm Features TIG Welded Construction
• CNC Machined 6061 Aluminum Step Bushings with Zinc Plated Steel Sleeves
• Energy Suspension Fluted Polyurethane grease able Bushings
• Uses OEM Hardware

Warranty: UMI Performance offers a 2 Year replacement Warranty from the original purchase date to the original purchaser of the parts.

Also available in Black Powdercoat:

Fitment Details
